SuperProx 16 teeth Gearbox output pinionRef : SUP00342A / PA60616

16-Tooth Output Sprocket by SuperProx

16-tooth output sprocket made from SCM45 treated steel, designed to minimise wear associated with road use. The perforated profile reduces the weight of the part for easier handling during installation, and the self-cleaning teeth help limit dirt accumulation between the teeth. 525 pitch and standard version for a replacement that meets the manufacturer's technical specifications.

Design and Materials

• High-strength treated steel "SCM45" providing good wear resistance and durability suitable for replacement
• Perforated sprocket to reduce the overall weight and facilitate handling during installation
• Self-cleaning teeth that limit dirt accumulation between the teeth and contribute to more consistent performance
• 525 pitch and 16 teeth, useful information for selecting the appropriate sprocket for your final drive
• OEM Reference CST-314:16.2

Practicality and Features

• Standard version for direct replacement on transmissions designed for this type of sprocket
• Accurate technical specifications to facilitate precise installation and limit adjustments during replacement
• Manufactured by SUPERSPROX, a motorcycle sprocket manufacturer since 1959, bringing recognised expertise in the production of transmission parts

Compatible Motorcycle Examples

• HONDA XRV 750 AFRICA TWIN 750 (2000)

Complete list of compatible motorcycles available in the dedicated section below
